Technical Specifications

Meter Base Surge Arrestor

Applications

120 VAC-240 VAC Surge Arrestor for residential usage. Installed at wattmeter, safely clamps and dissipates lightning induced AC line high voltage current impulses going to a residence. Also protects against AC line temporary overvoltage conditions.

Features

Meter surge arrestor

  • 40,000 amp peak capability, each 120 VAC leg
  • 210 VAC, continuous 5 minute, temporary overvoltage clamping capacity.
  • Lowest, reliable voltage clamping level.
  • Safety fusing, both 120 VAC legs
  • Patented LED “unit good” indicators, both 120 VAC legs
  • Fire-proof and explosion-proof polycarbonate glass-fiber reinforced enclosure with matching mounting connector
  • Sealed unit except for mounting connector wiring opening
  • For less inductance, 10# AWG tinned wires

Electrical and Environmental Specs

Triple surge electrical chart

Telephone Line Surge Arrestor Specs

Phone surge protector

  • Surge clamp peak voltage with 1,000 volt unipolar 8/20 µsec current impulse with 3,000 amp source capability
  • Metallic (tip to ring) = 310 volts average
  • Longitudinal = 310 volts average
  • Series Loop resistance = 80 ohms

Coax Line Surge Arrestor Specs

Coax surge arrestor

  • 8/20 µsec single impulse withstand capability (20,000 amps)
  • Protects from line to ground
  • Operating Frequency = 0 – 1 GHz
  • Response Time <5 nano seconds
